EU Machinery Directive Compliant
Available Models
ZMK5-5/PVC
Straight Female,single head
ZMS5-10/PVC
Straight Male,single head
ZMK5-5-ZMS5/PVC
Straight Female/Male,Double head
ZMK5-10-ZMS5/PVC
5-pin，7/8”connector
Series Technical Specifications
Connector
7/8” Standard Power Connector
Type
Male / Female / Extension Cable
Pins
5-pin
Material
PVC / PUR Cable Options
Length
2 m / 5 m / 10 m
Voltage
10...30 VDC
Current
5.3–7.7 A
Protection
IP67(screwed together)
Temperature
-30...90°C Connector / -40...80°C Cable
Contacts
CuZn Gold-plated Contacts
Seal
TPU Body / Viton Seal
Conductor
4×1.11 + 0.75 mm², 8.5 mm OD
Core Advantages
Standardized & compatible
No special cables needed, works with existing setups
Cost-effective upgrade
Evolves existing tech, no system replacement, cuts complexity
Comprehensive ecosystem
Multi-protocol masters + diverse slaves, full-link coverage
Efficient & reliable
Low-cost transmission, boosting efficiency while reducing costs
