EU Machinery Directive Compliant
Available Models
4M12-3P1-J
M12, 4-channel single signal
8M12-2PF-J/F
M12, 8-channel single signal
8MM8-3N1-5
M8, 8-channel single signal
8MM8-3P1-P
With on-site diagnosis function
Series Technical Specifications
Ports
4 / 8 Ports
Interface
M8 / M12 Standard Interfaces
Terminal
Customized Cable / Pluggable / Spring Clamp
Group Terminal
M23 12-pin / 19-pin Options
Signal
Single / Dual Signal Per Channel
Input
PNP / NPN Input Options
Output
Solenoid Valve Output
Wiring
Passive 1:1 Connection
Power
10–30 VDC
Current
10 A Rated / 2 A Per Channel
Diagnostics
Green Power LED / Yellow I/O LED
Protection
IP65 Protection Class
Core Advantages
Standardized & compatible
No special cables needed, works with existing setups
Cost-effective upgrade
Evolves existing tech, no system replacement, cuts complexity
Comprehensive ecosystem
Multi-protocol masters + diverse slaves, full-link coverage
Efficient & reliable
Low-cost transmission, boosting efficiency while reducing costs
